Husqvarna Chainsaw Parts Fast Guide
Husqvarna Chainsaw Parts Fast Guide
Using your Husqvarna chainsaw model # with this guide will help you find commonly replaced Husqvarna chainsaw parts. Click the name of the part you are looking for on the left chart & you will be taken to that parts section on the right chart.
- Sparkplug: Spark plugs supply the spark that ignites the air/fuel mixture, creating the explosion that makes your engine produce power
- Air Filter: Air Filters prevent saw dust, debris and dirt from getting into the internal parts of the chainsaw engine
- Fuel Filter: The fuel filter is a filter in the fuel line that screens out dirt and rust particles from the fuel allowing your chainsaw to start easily.
- Ignition Module: is an electronic switch that transfers signals to the ignition coil that makes the spark plugs fire and start your engine.
- Ignition Switch: When engaged, the switches ground the ignition coil to the engine causing the spark generation to cease.
- Fuel/Oil Tank Cap: Caps cover filler inlet.
- Carburetor: Regulates fuel and air mixture to allow for proper combustion.
- Clutch Assembly: Power take off from crankshaft to cutting equipment.
- Starter Cord: Wraps around starter pulley to allow for engine start.
- Starter Handle: T Grip handle to allow for pulling cord
- Starter Pawl / Springs: engages recoil assembly to flywheel.
- Recoil Assembly: complete assembly including starter cord, recoil spring and recoil housing
Sparkplug:
| Model Fit up | Part Type | Part # |
|---|---|---|
| 120II, 3120XP | Spark Plug | 503235111 |
| 395XP | Spark Plug | 952030249 |
| 130, 135II, 240, 435eII, 440eII, 445eII, 450eII, 455 Rancher, 565, 572XP, 365, 372XP, 390XP, 572XPG | Spark Plug | 503235111 |
| T525 | Spark Plug | 503235401 |
| T435, 439, 555, 545II, 550XPII, 562XP, T540XP II, 562XPG, 585, 592XP, 592XPG | Spark Plug | 531008615 |
| 543XP | Spark Plug | 506615101 |
| 460 Rancher | Spark Plug | 577484001 |
Air Filter:
| Model Fit up | Part Type | Part # |
|---|---|---|
| 555 | Air Filter | 505126307 |
| 562XP, 562XPG | Air Filter | 522675004 |
| T435 572XP, 365, 372XP, 390XP, 572XPG |
Air Filter | 527674701 |
| 460 Rancher | Air Filter | 537255703 |
| 395XP 592XP, 592XPG |
Air Filter | 537444401 |
| 445eII, 450eII | Air Filter | 544080803 |
| 435eII, 440eII | Air Filter | 599729402 |
| 120II, 240 | Air Filter | 545061801 |
| 365 | Air Filter | 575269103 |
| 565 | Air Filter | 575526402 |
| 585, 592XP, 592XPG | Air Filter | 593258802 |
| 572XP, 572XPG | Air Filter | 596762302 |
| 455 Rancher | Air Filter | 575789403 |
| 439 | Air Filter | 579308901 |
| T540XP II | Air Filter | 586092401 |
| 130 | Air Filter | 588229301 |
| 135 II | Air Filter | 588229302 |
| 545 II, 550XP II | Air Filter | 590458802 |
| T525 | Air Filter | 597176001 |
| 3120XP | Air Filter | 503895301 |
| 3120XP | Pre Air Filter | 503141802 |
| 390XP | Standard Air Filter | 537014703 |
| 395XP | Standard Air Filter | 575269103 |
| 543XP | Air Filter (SN 201722 and above) | 588849101 |
Fuel Filter:
| Model Fit up | Part Type | Part # |
|---|---|---|
| 3120XP | Fuel Filter | 503517101 |
| 543XP | Fuel Filter | 506742601 |
| 439, T525, T435 | Fuel Filter | 575960701 |
| 120II, 240 | Fuel Filter | 577167201 |
| 130, 135II, 435eII, 440eII, 445EII, 450eII, 455 Rancher, 460 Rancher, 545II, 550XPII, 555, 562XP, 565, 572XP, T540XP II, 365, 372XP, 390XP, 395XP, 562XPG, 572XPG 592XP, 592XPG | Fuel Filter | 591375401 |
| 585, 592XP, 592XPG | Fuel Filter | 503443203 |
Ignition Module:
| Model Fit up | Part Type | Part # |
|---|---|---|
| 395XP | Ignition Module | 503639801 |
| 390XP | Ignition Module | 510114902 |
| 460 Rancher | Ignition Module | 544047001 |
| 120II, 240 | Ignition Module | 575803501 |
| 435eII, 440eII, 445eII, 450eII 592XP, 592XPG | Ignition Module | 579638805 |
| 565 | Ignition Module | 582105002 |
| 545II | Ignition Module | 582777304 |
| 550XPII | Ignition Module | 582777404 |
| 439, T435 | Ignition Module | 584403701 |
| 455 Rancher | Ignition Module | 586815002 |
| 372XP | Ignition Module | 586880304 |
| T540XP II | Ignition Module | 587306804 |
| 3120XP | Ignition Module | 587329401 |
| T525 | Ignition Module | 587874901 |
| 572XP, 572XPG | Ignition Module | 588193102 |
| 543XP | Ignition Module | 588849001 |
| 365 | Ignition Module | 588937403 |
| 130, 135II | Ignition Module | 591466501 |
Ignition Switch:
| Model Fit up | Part Type | Part # |
|---|---|---|
| 585 | Ignition Module | 529965301 |
| 592XP, 592XPG | Ignition Module | 529965401 |
| 562XP, 562XPG | Ignition Module (2012+) | 581723402 |
| 555 | Ignition Module (2012+) | 581723502 |
| 395XP, 3120XP | Ignition Switch | 503717901 |
| 365, 372XP, 390XP, | Ignition Switch | 503718201 |
| 572, 572XPG | Ignition Switch | 510017202 |
| T525, T540XPII | Ignition Switch | 522798201 |
| 439 | Ignition Switch | 522798202 |
| T435, 543XP | Ignition Switch | 586246801 |
| 585, 592XP, 592XPG | Ignition Switch | 593260801 |
| 120II, 130, 135II, 240, 435eII, 440eII, 445EII, 450eII, 455 Rancher, 460 Rancher, 545II, 550XPII, 555, 562XP, 565, 572XP, 562XPG | Not applicable for these models |
Not applicable for these models |
Fuel/Oil Tank Cap:
| Model Fit up | Part Type | Part # |
|---|---|---|
| 543XP | Oil Tank Cap | 511064301 |
| 543XP | Fuel Tank Cap | 580759101 |
| 435eII, 440eII, 445EII, 450eII, 455 Rancher, 545II, 550XPII, 555, 562XP, 565, 572XP, 572XPG, 562XPG, 585, 592XP, 592XPG | Fuel / Oil Tank Cap | 522620003 |
| 460 Rancher | Fuel / Oil Tank Cap | 537215207 |
| 365, 372XP, 390XP, 395XP, 3120XP | Fuel / Oil Tank Cap | 537215207 |
| 120II, 240 | Fuel / Oil Tank Cap | 544111203 |
| 130, 135II | Fuel / Oil Tank Cap | 544111203 |
| 439, T435, T525, T540XP II | Fuel / Oil Tank Cap | 577878603 |
Carburetor:
| Model Fit up | Part Type | Part # |
|---|---|---|
| 395XP | Carburetor | 501355101 |
| 390XP | Carburetor | 501355201 |
| 562XP, 562XPG | Carburetor | 501463305 |
| 3120XP | Carburetor | 503281216 |
| 372XP | Carburetor | 503281805 |
| 585, 592XP, 592XPG | Carburetor | 598932901 |
| 445eII, 450eII | Carburetor | 506450401 |
| 435eII, 440eII | Carburetor | 506450501 |
| 460 Rancher | Carburetor | 544883001 |
| T435 | Carburetor | 578936901 |
| 439 | Carburetor | 579308001 |
| 455 Rancher | Carburetor | 580306303 |
| 365 | Carburetor | 581100701 |
| T540XP II | Carburetor | 586341402 |
| 120II, 240 | Carburetor | 586936202 |
| T525 | Carburetor | 587870501 |
| 130, 135II | Carburetor | 588247901 |
| 572XP, 572XPG | Carburetor | 591158301 |
| 565 | Carburetor | 591158302 |
| 550XPII | Carburetor | 596219201 |
| 545II | Carburetor | 596219202 |
| 555 | Carburetor (2012+) | 501463306 |
| 543XP | Carburetor (SN 201722 and above) | 580798401 |
Clutch Assembly:
| Model Fit up | Part Type | Part # |
|---|---|---|
| 3120XP | Clutch Assembly | 503144903 |
| 365 | Clutch Assembly | 503432001 |
| 395XP | Clutch Assembly | 503701502 |
| 390XP | Clutch Assembly | 537257501 |
| T525 | Clutch Assembly | 511044501 |
| 439, T435 | Clutch Assembly | 521557401 |
| 120II, 130, 135II, 240 | Clutch Assembly | 530014949 |
| 445EII, 450eII, 455 Rancher, 460 Rancher | Clutch Assembly | 537110503 |
| 435eII, 440eII | Clutch Assembly | 575568001 |
| 545II, 550XPII | Clutch Assembly | 577518202 |
| 543XP | Clutch Assembly | 585006001 |
| 372XP | Clutch Assembly | 586798401 |
| 565, 572XP, 572XPG | Clutch Assembly | 586798404 |
| T540XP II | Clutch Assembly | 586864001 |
| 585, 592XP, 592XPG | Clutch Assembly | 599231002 |
| 555, 562XP, 562XPG | Clutch Assembly | 589809002 |
Starter Handle:
| Model Fit up | Part Type | Part # |
|---|---|---|
| 390XP, 395XP, 3120XP | Starter Handle | 503543901 |
| 365, 372XP | Starter Handle | 522037301 |
| 435eII, 439, 440eII, 445EII, 450eII, 455 Rancher, 460 Rancher, T435, 543XP, 545II, 550XPII, 555, 562XP, 565, 572XP, 562XPG, 572XPG, 585, 592XP, 592XPG | Starter Handle | 537232501 |
| 120II, 130, 135II, 240 | Starter Handle | 545010010 |
| T540XP II | Starter Handle | 584156201 |
| T525 | Starter Handle | 593587302 |
Starter Cord:
| Model Fit up | Part Type | Part # |
|---|---|---|
| 365, 372XP, 390XP, 585, 592XP, 592XPG | Starter Cord | 503432902 |
| 395XP, 3120XP | Starter Cord | 503432903 |
| 435eII, 440eII, 445EII, 450eII | Starter Cord | 503858901 |
| 545II | Starter Cord | 503858902 |
| T540XP II | Starter Cord | 505305103 |
| 455 Rancher, 460 Rancher, 550XPII, 555, 562XP, 565, 572XP, 562XPG, 572XPG | Starter Cord | 505305125 |
| T525 | Starter Cord | 513417101 |
| 439, T435 | Starter Cord | 522645101 |
| 543XP | Starter Cord | 527756101 |
| 120II, 130, 135II, 240 | Starter Cord | 545010010 |
Starter Pawl / Springs:
| Model Fit up | Part Type | Part # |
|---|---|---|
| 550XPII | Starter Pawl and Spring Kit | 596230601 |
| 555, 572XP, 572XPG | Starter Pawl and Spring Kit | 590281301 |
| 545II | Starter Pawl and Spring Kit | 596230601 |
| 543XP | Starter Pawl | 576982501 |
| 543XP | Starter Spring | 514240901 |
| 555, 562XP, 395XP, 3120XP, 562XPG | Starter Pawl | 501673201 |
| 555, 562XP, 395XP, 3120XP, 562XPG | Starter Spring | 501673501 |
| 585, 592XP, 592XPG | Starter Pawl and Spring Kit | 597960601 |
| T525 | Starter Pawl | 521551701 |
| T525 | Starter Spring | 521551801 |
| 365, 372XP, 390XP | Starter Pawl | 537015501 |
| 365, 372XP, 390XP | Starter Spring | 501673501 |
| 435eII, 440eII, 445eII, 450eII, 455 Rancher, T540XPII, 460 Rancher | Starter Pawl | 537245601 |
| 435eII, 440eII, 445eII, 450eII, 455 Rancher, T540XPII, 460 Rancher | Starter Spring | 529271101 |
| 130, 135II | Flywheel Kit, includes Pawls and Springs |
544874202 |
| 120II, 240 | Flywheel Kit, includes Pawls and Springs |
575635502 |
| 439 | Flywheel Kit, includes Pawls and Springs |
581972001 |
| T435 | Flywheel Kit, includes Pawls and Springs |
581972001 |
Recoil Assembly:
| Model Fit up | Part Type | Part # |
|---|---|---|
| 3120XP | Recoil Assembly | 501896502 |
| 395XP | Recoil Assembly | 503462402 |
| 365, 372XP | Recoil Assembly | 503628171 |
| 555, 562XP, 562XPG | Recoil Assembly | 505159204 |
| 585, 592XP, 592XPG | Recoil Assembly | 598781201 |
| T540XP II | Recoil Assembly | 506902104 |
| T435 | Recoil Assembly | 522012501 |
| 390XP | Recoil Assembly | 537003871 |
| 460 Rancher | Recoil Assembly | 537284201 |
| 120II, 240 | Recoil Assembly | 545008025 |
| 455 Rancher | Recoil Assembly | 574643201 |
| 565, 572XP, 572XPG | Recoil Assembly | 575527604 |
| 439 | Recoil Assembly | 579309801 |
| 445eII, 450eII | Recoil Assembly | 579425311 |
| 435eII, 440eII | Recoil Assembly | 579425406 |
| 550XPII | Recoil Assembly | 588415103 |
| 130 | Recoil Assembly | 591466701 |
| T525 | Recoil Assembly | 596914001 |
| 135II | Recoil Assembly | 591466702 |
| 543XP | Recoil Assembly (SN 201722 and above) | 586693102 |
| 545II | Recoil Assembly | 596230501 |
Cant find the parts you are looking for?. Use our Parts Lookup Diagrams
